CHZ-ST45 High-Pressure Die-Cast Aluminum Street Light with Adjustable Installation Angle and Various Beam Angles
5.0
MODEL:
CHZ-ST45
LED CHIPS:
SMD5050
COLOR TEMPERATURE:
3000K / 4000K / 5000K / 5700K / 6500K
DRIVERS:
MEAN WELL / PHILIPS / SOSEN / INVENTRONICS
BEAM ANGLE:
ΤYPE I / ΤYPΕ II / ΤYPE III / TYPE V
REGULATION:
0-10V / PMW / DALI
VOLTAGE:
100 - 277V
POWER FACTOR:
> 0.95
ELECTRICAL CATEGORY:
Class I / Class II
MATERIALS:
AL housing / AL heatsink / PC lens
PROTECTION(IP / IK):
IP66 / IK09
INSTALLATION:
Ø 60 mm
LIFETIME / WARRANTY:
50,000 hours / 5 years
WORKING ENVIRONMENT:
- 40ºC ~ + 50ºC / 10%-90%RH
STORAGE TEMP:
CE CB ENEC+ ENEC ROHS ISO9001 ISO14001 ISO50001 ISO45001
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Product Description
CHZ-ST45 High-Pressure Die-Cast Aluminum Street Light with Adjustable Installation Angle and Various Beam Angles
1. High pressure die-casting aluminum housing wth quick heat ventilation.
2. Excellent thermal management and outstanding self-cleaning capability.
3. High efficient SMD5050 chips and high quality driver, assures long lifetime.
4. Multiple beam angle optics for options according to various lighting applications.
5. With movable handle, the installation angle is adjustable from 0-90 °; the lamp housing can be
opened manually, and the power is automatically cut off, which is convenient for maintenance.
| Model No. | Power(W) | Chips | Chips Qty | Chips S/P | Protection Class | Lumen(LM/W） | ||
| ST45-30W(XS) | 30 | SMD5050 | 24 | 2S12P | Class I / II | >160 | ||
| ST45-40W(XS) | 40 | SMD5050 | 24 | 2S12P | Class I / II | >160 | ||
| ST45-50W(S) | 50 | SMD5050 | 36 | 2S18P | Class I / II | >160 | ||
| ST45-60W(S) | 60 | SMD5050 | 36 | 2S18P | Class I / II | >160 | ||
| ST45-80W(M) | 80 | SMD5050 | 54 | 2S27P | Class I / II | >160 | ||
| ST45-100W(M) | 100 | SMD5050 | 54 | 2S27P | Class I / II | >160 | ||
| ST45-120W(L) | 120 | SMD5050 | 96 | 2S48P | Class I / II | >160 | ||
| ST45-150W(L) | 150 | SMD5050 | 96 | 2S48P | Class I / II | >160 | ||
| ST45-200W(XL) | 200 | SMD5050 | 144 | 2S72P | Class I / II | >160 | ||
| ST45-240W(XL) | 240 | SMD5050 | 144 | 2S72P | Class I / II | >160 | ||
SMD5050 High quality LED wick
Low power consumption and high brightness
SMD LED Chips
Hiah Brightness
100-277V
Efficient Cooling
Service life
Optional optical controller
High pressure die-casting aluminum
PC lens and GLASS cover
Respirator design
Smart control and dimmable zhaga
10KV or 20KV Surge protection device
Toolless open clip
Pole mounted
Application Scenario
Widely used in trunk roads, highways, elevated roads, streets, bridges, sidewalks and other road lighting, as well as squares, schools, parks and other outdoor lighting needs.
