CHZ Lighting - LED Street Light Manufacturer and LED Flood Light Factory Since 2013
CHZ Lighting New street lighting fixture factory for road
MODEL:
CHZ-ST35
LED CHIPS:
LUMILEDS 5050
COLOR TEMPERATURE:
3000K / 4000K / 5000K / 5700K / 6500K
DRIVERS:
SOSEN / INVENTRONICS
BEAM ANGLE:
TYPE II TYPE III TYPE V
REGULATION:
0-10V/ Timer / DALI
VOLTAGE:
100 - 277V / 200~240V
POWER FACTOR:
> 0.95
ELECTRICAL CATEGORY:
Class I / Class II
MATERIALS:
AL housing / AL heatsink / PC lens
PROTECTION(IP / IK):
IP66 - IK09
INSTALLATION:
Ø 60 mm
LIFETIME / WARRANTY:
50,000 hours / 5 years
WORKING ENVIRONMENT:
- 35ºC ~ + 50ºC / 10%-90%RH
CERTIFICATIONS:
CE CB ENEC+ ENEC ROHS ISO9001 ISO14001 ISO50001 ISO45001
street lighting fixture
description
This product has reliable quality and stable performance. Constructed with top Philips 5050 or 3030 chips, it features high luminous efficiency
street lighting fixture
SPECIFICATIONS
| MODEL | CHZ-ST35 |
|---|---|
| LED CHIPS | LUMILEDS 5050 |
| COLOR TEMPERATURE | 3000K / 4000K / 5000K / 5700K / 6500K |
| DRIVERS | SOSEN / INVENTRONICS |
| REGULATION | 0-10V/ Timer / DALI |
| VOLTAGE | 100 - 277V / 200~240V |
| POWER FACTOR | > 0.95 |
| ELECTRICAL CATEGORY | Class I / Class II |
| BEAM ANGLE | TYPE II TYPE III TYPE V |
| MATERIALS | AL housing / AL heatsink / PC lens |
| PROTECTION(IP / IK) | IP66 - IK09 |
| INSTALLATION | Ø 60 mm |
| LIFETIME / WARRANTY | 50,000 hours / 5 years |
| WORKING ENVIRONMENT | - 35ºC ~ + 50ºC / 10%-90%RH |
| CERTIFICATIONS | CE CB ENEC+ ENEC ROHS ISO9001 ISO14001 ISO50001 ISO45001 |
Adopting an intelligent constant current driver, it has no flicker problem. Its correlated color temperature(CCT) can be customized. Designed with dust and water resistance, it reduces the pressure of cleaning and maintenance.
