CHZ Lighting - LED Street Light Manufacturer and LED Flood Light Factory Since 2013
reliable led street light for sale suppliers bulk production
1. The design of CHZ led street light for sale requires to consider different aspects. It is engineered for the functions of specific wearing purposes, as well as considering the common types of foot types and arch types. This product is made in line with the "green low carbon" proposed by the state
2. This product is environmentally friendly. It is free of lead and mercury and thus contributing to the sustainability of the environment. It is able to work under humidity ranging from 10% to 90
3. This offered product brings direct performance benefits to the buyer. It is widely exported to over 60 countries and regions
- Light Source:
-
LED
- Input Voltage(V):
-
100-277V
- Lamp Luminous Flux(lm):
-
13000
- CRI (Ra>):
-
70
- Working Temperature(℃):
-
-35^ 50
- IP Rating:
-
IP66
- Certification:
-
ce, EMC, LVD, RoHS
- Warranty(Year):
-
5
- Place of Origin:
-
Shanghai, China
- Brand Name:
-
CHZ
- Model Number:
-
CHZ-ST29-100W
- Beam Angle(°):
-
145°x80°
- Application:
-
ROAD
- Color:
-
Light Grey, Black, White, Dark Grey
- Power Supply:
-
AC
- Power:
-
30W 40W 50W 60W 80W 100W 120W 160W 180W 200W
- Lumen (Lm/W):
-
>130LM/W
- LED'S type:
-
SMD3030
- Aperture dia (mm):
-
D60mm
- Protection level:
-
IP66/IK09/10KV or 20KV
- RA:
-
>70 or >80,According to the actual needs of customers
- PF:
-
>0.95
- control method:
-
Ordinary, 0-10V, PMW, DALI and other intelligent controls
- Light shell spraying:
-
Gray, black or white
- Work humidity:
-
10%~90%
- Working Lifetime(Hour):
-
50000
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 67X28X16 cm
- Single gross weight:
- 6.000 kg
- Package Type:
- 1, Neutral packaging for led lights. 2, Kraft paper and high-grade EPE packing material are being used to make sure the safety of shipping. 3, Corrugated outer carton (K=K) for LED light.
- Picture Example:
-
- Lead Time :
-
Quantity(Pieces) 1 - 1 2 - 10 >10 Est. Time(days) 7 15 To be negotiated
smart city lighting led sensor street light 100 watt led road light lamp ip66 with Best Price
Features:
High pressure die-casting aluminum housing with quick heat ventilation;
Excellent thermal management and outstanding self-cleaning capability;
High dfficient SMD3030 Led chips and high quality driver, assures long lifetime;
Multiple beam angle optics for options according to various lighting applications.
Applications:
Wilely used in trunk roads, higways, elevated roads, streets, bridges, sidewalks and other rad ligting, as well as squares, schools, parks and other outdoor lighting needs.
Parameter:
Model | ST29-30WMi | ST29-40WMi | ST29-50WMi |
Power | 30W | 40W | 50W |
LED type | SMD 3030 | SMD 3030 | SMD 3030 |
LED`s | 72PCS | 72PCS | 108PCS |
Connection | 6S12P | 6S12P | 6S12P |
Model | ST29-60WS | ST29-80WS | ST29-100WS |
Power | 80W | 90W | 100W |
LED type | SMD 3030 | SMD 3030 | SMD 3030 |
LED`s | 144PCS | 72PCS | 108PCS |
Connection | 8S18P | 8S18P | 8S18P |
Model | ST29-100WM | ST29-120WM | ST29-150WM |
Power | 120W | 140W | 150W |
LED type | SMD 3030 | SMD 3030 | SMD 3030 |
LED`s | 192PCS | 192PCS | 192PCS |
Connection | 8S24P | 8S24P | 8S24P |
Model | ST29-160WL | ST29-180WL | ST29-200WL |
Power | 160W | 180W | 200W |
LED type | SMD 3030 | SMD 3030 | SMD 3030 |
LED`s | 240PCS | 240PCS | 240PCS |
Connection | 8S30P | 8S30P | 8S30P |
Lumen(Lm/W) | >130LM/W | ||
CCT | 3000K/4000K/5000K/5700K,According to the actual needs of customers | ||
Beam angle | 117°x 52° | ||
RA | >70 or >80,According to the actual needs of customers | ||
Drive type | 100-277V | ||
Input Volt | >0.95 | ||
PF | MW, INVENTRONICS or other, according to customer needs | ||
control method | Ordinary, 0-10V, PMW, DALI and other intelligent controls, according to customer's actual needs | ||
Product Size | 794x320x122mm | ||
Light body material | Die-casting aluminum lamp body + tempered glass cover +304 stainless steel screws | ||
Light shell spraying | Gray, black or white | ||
Installation diameter | 60mm | ||
Protection level | IP66/IK08 | ||
Lightning protection level | 10KV or 20KV, according to the actual needs of customers | ||
Work temp | —35℃~+50℃ | ||
Work humidity | 10%~90% | ||
Life/Warranty | 50,000hrs / 5YEARS | ||
1. What are your market reach throughout the regiion?
Our markets around the world in every corner, we have many years of experience in foreign trade.Our clients are from different countries. And we have branch office in Spain and Nigeria.
2. Whar are your main products?
Our main products are led outdoor lightings including led flood light( stadium lighting), led high bay light, led street lighting and led garden light.
3. Are you a manufactuer or a trading company?
We are a professional LED manufacturer.
4. Do you have the ability to do independent research and development?
Our engineering department have the research and development capabilities. We also collect regular customer feedback to research new product.
5. How to contact you?
Welcome to vist our websit (www.chz-lighting.com) to get more information.
Company Features
1. With rich production experience, Shanghai CHZ Lighting Co.,Ltd has become one of the leading domestic manufacturers of .
2. CHZ employs advanced techniques to produce high quality led street light for sale .
3. Excellent quality and superb service all comes from CHZ. Get more info!
