Outdoor LED Lawn Light Fixture CHZ-CPL01

MODEL:

CHZ-CPL01

LED CHIPS:

SMD2835

COLOR TEMPERATURE:

3000K / 4000K / 5000K / 5700K / 6500K

DRIVERS:

Eaglerise

BEAM ANGLE:

90°

VOLTAGE:

200-240V

POWER FACTOR:

>0.9

MATERIALS:

AL Body PC lens and GLASS cover

LIFETIME / WARRANTY:

50,000 hours / 5 years

WORKING ENVIRONMENT:

- 30ºC ~ + 50ºC / 10%-90%RH

PROTECTION(IP - IK - KV):

IP65 - IK10

LUMEN:

100LM/W

CRI:

>70

CERTIFICATIONS:

CE ROHS ISO9001 ISO14001 ISO50001 ISO45001

Inquiry

Write a Review

Parameters

Main body is made of Die-casting aluminum alloy with Extruded aluminum alloy. The diffuser is a frosted anti-UV polycarbonate for high efficiency and vandal resistance.

Lumileds 2835 LED chip and Philips driver as regular, Tridonic, Eaglerise, Kegu driver options.Easy access to LED and driver via a removable head.

3000-6500K color temperature options; Tamper prooffixings for increased vandal resistance.

P65 and IK10 protection degree.

Anti-UV electrostatic powder spraying, regula rcor: Black, Silver, RAL7043, RAL7016.

Model No.	Power(W)	Chips	Lumen(LM/W)	Beam Angle	Size(φ×H)mm
CPL01-400	10-20	SMD2835	>100	90°	230×400
CPL01-600	10-20	SMD2835	>100	90°	230×600
CPL01-800	10-20	SMD2835	>100	90°	230×800

Product Feature

1. Main body is made of Die-casting aluminum alloy with Extruded aluminum alloy.
2. The diffuser is a clear anti-UV polycarbonate for high efficiency and vandal resistance.
3. Lumileds 2835 LED chip and Eaglerise driver as regular, Tridonic, Philips, Kegu driver options.
4. Easy access to LED and driver via a removable head.
5. Tamper proof fixings for increased vandal resistance.
6. Anti-UV electrostatic powder spraying, Black, Silver, RAL7043, RAL7016 color optional.
7. lP65 and IK10 protection degree.

Outdoor LED Lawn Light Fixture CHZ-CPL01 4

Outdoor LED Lawn Light Fixture CHZ-CPL01 5

Applications

Widely used in factories, mines, plazas, transportation hubs, stadiums, golf courses and docks.

▪ They can provide bright lighting across roads, building exteriors, small/medium sized sports sites, parking lots, etc., thereby enhancing safety and security;

▪ With exceptional energy efficiency, these lights reduces operational costs, which makes them perfectly suitable for extended nighttime use.
