    Overview
    Quick Details
    Lighting solutions service:
    DIALux evo layout
    Light Source:
    LED
    Lamp Luminous Flux(lm):
    7500
    CRI (Ra>):
    70
    Working Temperature(℃):
    -40℃~+50℃
    IP Rating:
    IP66
    Certification:
    ce, EMC, LVD, RoHS
    Warranty(Year):
    5-Year
    Place of Origin:
    Shanghai, China
    Brand Name:
    CHZ
    Model Number:
    CHZ-ST25B smd3030
    Beam Angle(°):
    145°x 75°(TYPE II)
    Application:
    ROAD
    Color:
    Black, Dark Grey, Light Grey, White
    Power Supply:
    AC
    Power:
    60W 80W 100W
    Lumen (Lm/W):
    >150lm/w
    LED'S type:
    SMD5050
    Aperture dia (mm):
    D60
    IP:
    IP66
    IK:
    IK10
    PF:
    >0.95
    Product Keywords:
    new module street lighting with pole
    Input Voltage(V):
    100-277V
    Working Lifetime(Hour):
    50000
    Luminous Efficacy(lm/w):
    150
    Supply Ability
    Supply Ability:
    10000 Piece/Pieces per Month
    Product Description

    Led street light with outdoor cctv camera nigeria soncap cetificate pc certificate

    Products Parameter of new led street light CHZ-ST25B:

    Model

    ST25-60WB

    ST25-80WB

    ST25-100WB

    Rated power

    60W

    80W

    100W

    Lamp Bead Type

    SMD3030

    SMD3030

    SMD3030

    Number of lamp beads

    160 PCS

    160 PCS

    160 PCS

    Serial-parallel

    20P8S

    20P8S

    20P8S

    Light effect Lm / W

    >150

    Light source voltage

    48V

    48V

    48V

    Light source current

    1200mA

    1600mA

    2000mA

    Driving working voltage

    100-244V/277V AC

    Power factor PF

    >0.95

    CCT

    3000K/4000K/5000K/5700K/6500K

    Color rendering RA

    >70

    Beam angle

    145°x 75°(TYPE II)

    Fixture size

    717x178x99mm

    717x178x99mm

    717x178x99mm

    Lamp holder mounting diameter

    D60 mm

    Light body material

    Die-casting lamp body + PC lens

    Protection class

    IP66&IK10

    Operating temperature

    —40~+50

    Working humidity

    10%~90%

    Life / warranty period

    50,000 hours / 5 years


    Led street light with outdoor cctv camera nigeria sonacap certificate pc certificate 3

    PROJECTS

    Led street light with outdoor cctv camera nigeria sonacap certificate pc certificate 5

    Led street light with outdoor cctv camera nigeria sonacap certificate pc certificate 7Led street light with outdoor cctv camera nigeria sonacap certificate pc certificate 9Led street light with outdoor cctv camera nigeria sonacap certificate pc certificate 11

    FAQ:

    1. What are your market reach throughout the regiion?

    Our markets around the world in every corner, we have many years of experience in foreign trade.Our clients are from different countries. And we have branch office in Spain and Nigeria.



    2. Whar are your main products?

    Our main products are led outdoor lightings including led flood light( stadium lighting), led high bay light, led street lighting and led garden light.



    3. Are you a manufactuer or a trading company?

    We are a professional LED manufacturer.



    4. Do you have the ability to do independent research and development?

    Our engineering department have the research and development capabilities. We also collect regular customer feedback to research new product.



    5. How to contact you?

    Welcome to vist our websit (www.chz-lighting.com) to get more information.


    Related Products
    Related Products

    Led street light with outdoor cctv camera nigeria sonacap certificate pc certificate 13


    The product not only meets people's needs in terms of design and visual aesthetics but also is safe and durable, always meeting consumer expectations. Adopting an intelligent constant current driver, it has no flicker problem. With its abrasion resistance property, this product allows for many times of washing or a lot of people's movements. Adopting an intelligent constant current driver, it has no flicker problem.
