Parameter:
Model No. | FL13-30W | FL13-50W | FL13-80W |
Power | 30W | 50W | 80W |
LED type | SMD 3030 | SMD 3030 | SMD 3030 |
LED`s | 30 PCS | 50 PCS | 80 PCS |
Connection | 6P5S | 10P5S | 16P5S |
Chips Votl | 30V | 30V | 30V |
Chipt Current | 900mA | 1500mA | 2400mA |
Beam angle | 120° | 25°/50°/ 120° | 120° |
Product size | 227*167*45(mm) | 310*220*50(mm) | 354*245*55(mm) |
Model No. | FL13-100W | FL13-150W | FL13-200W |
Power | 100W | 150W | 200W |
LED type | SMD 3030 | SMD 3030 | SMD 3030 |
LED`s | 100 PCS | 150 PCS | 200 PCS |
Connection | 20P5S | 30P5S | 40P6S |
Chips Votl | 30V | 30V | 36V |
Chipt Current | 3000mA | 4500mA | 5000mA |
Beam angle | 25°/50°/120° | 25°/50°/120° | 25°/50°/120° |
Product size | 402*295*60(mm) | 430*330*60(mm) | 470*360*60(mm) |
Input Volt | 100-277V | ||
Power factor | >0.95 | ||
Lumen | >130 | ||
CCT | 3000-6500K | ||
CRI | >70 | ||
IP Degree | IP65 | ||
Light material | Die-cast AL body + glass cover + Respirator | ||
Work temp | —20℃~+60℃ | ||
Work humidity | 10%~90% | ||
Life/Warranty | 50,000hrs / 5 years |
FAQ:
1. What are your market reach throughout the regiion?
Our markets around the world in every corner, we have many years of experience in foreign trade.Our clients are from different countries. And we have branch office in Spain and Nigeria.
2. Whar are your main products?
Our main products are led outdoor lightings including led flood light( stadium lighting), led high bay light, led street lighting and led garden light.
3. Are you a manufactuer or a trading company?
We are a professional LED manufacturer.
4. Do you have the ability to do independent research and development?
Our engineering department have the research and development capabilities. We also collect regular customer feedback to research new product.
5. How to contact you?
Welcome to vist our websit (www.chz-lighting.com) to get more information.
