 CHZ Lighting -  LED Street Light Manufacturer and LED Flood Light Factory Since 2013

CHZ smart street lighting best manufacturer with high cost performance 1
CHZ smart street lighting best manufacturer with high cost performance 2
CHZ smart street lighting best manufacturer with high cost performance 3
CHZ smart street lighting best manufacturer with high cost performance 4
CHZ smart street lighting best manufacturer with high cost performance 5
CHZ smart street lighting best manufacturer with high cost performance 6
CHZ smart street lighting best manufacturer with high cost performance 7
CHZ smart street lighting best manufacturer with high cost performance 1
CHZ smart street lighting best manufacturer with high cost performance 2
CHZ smart street lighting best manufacturer with high cost performance 3
CHZ smart street lighting best manufacturer with high cost performance 4
CHZ smart street lighting best manufacturer with high cost performance 5
CHZ smart street lighting best manufacturer with high cost performance 6
CHZ smart street lighting best manufacturer with high cost performance 7

CHZ smart street lighting best manufacturer with high cost performance

Inquiry
Company Advantages
1. The production of CHZ includes overall three parts: the production of filament, the bulb, and the base, which is highly automated. The shape of the product will be changed according to the needs of the customers
2. When it comes to matters of fashion, this product could really matter a lot. It often reflects one's tastes and at times one's personality. The product is certified under CCC, TUV, CE, ROHS, UL, DLC, etc
3. It is thoroughly checked by the experts in order to ensure reliable performance without any flaws. Designed with quality heat sink fins, it features good heat dissipation
4. The product has long-term service, stable performance, and great durability, etc. It has a wide light beam angle, which offers enough brightness for certain areas
5. A complete quality management system has been specially established to ensure the quality of this product. It is widely exported to over 60 countries and regions
Overview
Quick Details
Lighting solutions service:
DIALux evo layout
Light Source:
LED
Lamp Luminous Flux(lm):
5200
CRI (Ra>):
70
Working Temperature(℃):
-35℃~+50℃
IP Rating:
IP66
Certification:
ce, RoHS
Warranty(Year):
5-Year
Place of Origin:
Shanghai, China
Brand Name:
CHZ
Model Number:
CHZ
Beam Angle(°):
117°x 52°
Application:
ROAD
Color:
Black, Dark Grey, White
Power Supply:
AC
Power:
40W
LED type:
SMD 3030
Light effect:
>130LM/W
Color temperature:
3000K/4000K/5000K/5700K/6500K,based on customer's needs
Power factor PF:
>0.95
Drive type:
MW, INVENTRONICS or others, according to customer needs
Lamp body material:
Die-cast aluminum body + tempered glass cover + 304 stainless steel sc
Protection level:
IP66/IK09 10KV or 20KV
Service life:
50,000hrs/5 years
Dimming method:
Ordinary, 0-10V, PMW, DALI and other intelligent controls
Input Voltage(V):
AC 100-277V 50/60HZ
Working Lifetime(Hour):
50000
Luminous Efficacy(lm/w):
130
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month
Product Description

5 years warranty road light luminary led lights projector for sale


Application:

It is widely used in public areas such as urban main roads, industrial parks, living quarters and squares;

Parameter:

Model

ST31-40WS

ST31-60WS

ST31-80WM

ST31-100WM

Power

40W

60W

80W

100W

LED type

SMD 3030

SMD 3030

SMD 3030

SMD 3030

LED's

96PCS

96PCS

144PCS

144PCS

Serialization

12P8S

12P8S

18P8S

18P8S

Product Size

535x200x120mm

535x200x120mm

655x275x110mm

655x275x110mm

Installation diameter

D50mm

D50mm

D60mm

D60mm

Model

ST31-120WM

ST31-150WM

ST31-180WL

ST31-200WL

Power

120W

150W

180W

200W

LED type

SMD 3030

SMD 3030

SMD 3030

SMD 3030

LED's

192PCS

192PCS

252PCS

252PCS

Serialization

24P8S

24P8S

32P8s

32P8S

Product Size

655x275x110mm

655x275x110mm

760x328x110mm

760x328x110mm

Installation diameter

D60mm

D60mm

D60mm

D60mm

Light effect

>130LM/W

CCT

3000K/4000K/5000K/5700K/6500K,based on customer's needs

Beam angle

117°x 52°

CRI

CRI > 70

Operating Voltage

100-277V

PF

>0.95

Drive type

MW, INVENTRONICS or others, according to customer needs

Dimming method

Ordinary, 0-10V, PMW, DALI and other intelligent controls, according to the actual needs of customers; can also be installed with light controller

Lamp body material

Die-cast aluminum body + tempered glass cover + 304 stainless steel screws

Protection level

IP66/IK09

Lightning protection level

10KV or 20KV

Operating temperature

—35~+50

Working humidity

10%~90%

Service life

50,000hrs/5 Years







CHZ smart street lighting best manufacturer with high cost performance 8CHZ smart street lighting best manufacturer with high cost performance 10CHZ smart street lighting best manufacturer with high cost performance 12CHZ smart street lighting best manufacturer with high cost performance 14CHZ smart street lighting best manufacturer with high cost performance 16

Project
Company Information

CHZ smart street lighting best manufacturer with high cost performance 24

CHZ Lighting Company view Specification of outdoor led street lights:

Established in 2010, Shanghai CHZ Lighting Co., Ltd. is a high-tech enterprise engaged in the research, development, production and sales of lighting products.



CHZ adheres to the standard of "leading technology and leading quality" and has established a joint R&D center with Professor Chen Dahua (Ph.D.) of Fudan University's electric light source department. It continues to develop new products and lead the smart trend. Our products cover industrial lighting, stadium lighting, street lighting and solar lighting. We insist on using high-quality raw materials and advanced production technology to focus on manufacturing every kind of high-quality lamps. Our factory has passed ISO9001: 2015 certification, ENEC, CE. , FCC, ROSH, TUV UL CB certification.





payment terms:

1. Payment method: wire transfer, sight letter of credit, Western Union remittance, Alipay

2. Samples can be delivered within 5-7 working days; Order: 10-20 days

3. Quote shipping according to your requirements

4. Freight Port: Shanghai, China

5. Offer discounts based on order quantity



Solution service process:

Understand the overall needs of customers, recommend related products and corresponding power, customers provide basic engineering information (taking road lighting as an example: customers need to provide road width, pole height, pole position, pole distance, average illumination requirements, etc.). Designers use Dialux simulation to design lighting effects and offer a variety of options for customer selection.



Shanghai CHZ LIGHTING always follows the standardization rules and implements strict production processes to ensure product quality, thus saving time and cost for both parties and bringing maximum benefits to customers.



FAQ:

1. What is a general business process?

Answer: Send inquiry to CHZ→(Customer provides engineering information→Dialux simulation design→Confirm design plan and product→) Specification confirmation→Quotation→Sample list confirmation→Form invoice→Payment bank document→Sample delivery→Sample satisfaction→Big order list→ Formal invoice → 30% deposit payment in advance → production ready → 70% balance bank check → delivery → after-sales service



2. What is the warranty?

A: According to different types of lamps, a 5-7 year warranty is provided. If the product fails during the warranty period due to quality problems, we will immediately send out new replacements and freight charges in case of emergency. Or, we prefer to send a replacement for the next order.



3. What is the payment period?

A: For sample orders, we can accept wire transfer 100% in advance, PayPal, Western Union. For large orders, please pay 30% deposit by wire transfer and pay 70% balance before shipment. For large orders, letters of credit


3. What is the payment term?
Answer : For sample order, we can accept T/T, Paypal, West Union, 100% in advance. For bulk order, 30% deposit in advance by T/T, 70% balance before shipping. For very big order, L/C is negotiable.

4. Can I add my logo on the product label?
Answer : Yes, but order quantity is requested depending on different lights.

5. I don't know which sty how many LED Street Light should I use, can you advise?
Answer : Yes, we can offer our professional solution for you, IES file is available if you have the design team.

6. Do you have any MOQ limit for led light order?
Answer: Low MOQ, 1pc for sample checking is available .

7. How do you ship the goods and how long does it take to arrive?
Answer: We usually ship samples and small quantities of products that customers need urgently with DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. High-volume product transportation is available for airline or maritime transportation. The shipping time is updated according to the actual situation of the shipping company.

8. We don't know how to install,can you help?
Answer : We offer both online and on-site installation instructions and testing. Please communicate with us in advance, we will negotiate to confirm the more appropriate guidance to ensure the smooth completion of the project.

9. How to deal with the faulty?
Answer : Firstly, Our products are produced in strict quality control system and the defective rate < 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will send out new replacement to you immediately for you to solve the problem.



10. It is not convenient for us to visit your company in China, but what if you want to know the strength of your company in more detail?
Answer : You can visit us by visiting our foreign branches. We have teams and warehouses in Spain, USA, Nigeria and Nicaragua can provide you with comprehensive pre-sales and after-sales protection. You can also pay attention to it through our official website and the FACEBOOK homepage .






This piece of furniture is functional and among timeless pieces that can easily fit in a space and also people's budget. Its correlated color temperature(CCT) can be customized. The product brings benefits to most people who have some problems with foot odor. It ensures that won’t get smelly even being worn for a whole day. Its correlated color temperature(CCT) can be customized.

Company Features
1. As a renowned manufacturer producing quality , Shanghai CHZ Lighting Co.,Ltd is developing rapidly to take superiority in the market through its quality and competitive prices.
2. Shanghai CHZ Lighting Co.,Ltd has a number of advanced testing equipment for smart street lighting .
3. The goal of Shanghai CHZ Lighting Co.,Ltd is to build a brand name through excellent quality and mature after-sales service. Ask!
