CHZ Lighting - LED Street Light Manufacturer and LED Flood Light Factory Since 2013
CHZ eco-friendly smart street lighting wholesale for promotion
30w 40w 50w 60w 80w 90w 120w 100 watt cob head led street light COB LED lamp Fixture
Parameter:
Model | ST15-30WB | ST15-40WB | ST15-50WB | ST15-60WB |
Power | 30W | 40W | 50W | 60W |
LED type | COB/Bridgelux | COB/Bridgelux | COB/Bridgelux | COB/Bridgelux |
LED`s | 1 PCS | 1 PCS | 1 PCS | 1 PCS |
Connection | 3P10S | 4P10S | 5P10S | 6P10S |
Light source voltage | 30V | 30V | 30V | 30V |
Input Volt | 100-277V | 100-277V | 100-277V | 100-277V |
PF | >0.95 | >0.95 | >0.95 | >0.95 |
Lumen(Lm/W) | >110LM/W | >110LM/W | >110LM/W | >110LM/W |
Product Size | 500x215x85 mm | 620x260x90 mm | ||
Model | ST15-80WB | ST15-90WB | ST15-100WB | ST15-120WB |
Power | 80W | 90W | 100W | 120W |
LED type | COB/Bridgelux | COB/Bridgelux | COB/Bridgelux | COB/Bridgelux |
LED`s | 2 PCS | 2 PCS | 2 PCS | 2 PCS |
Connection | (4P10S) *2 | (5P10S)*2 | (5P10S)*2 | (6P10S)*2 |
Light source voltage | 30V | 30V | 30V | 30V |
Input Volt | 100-277V | 100-277V | 100-277V | 100-277V |
PF | >0.95 | >0.95 | >0.95 | >0.95 |
Lumen(Lm/W) | >110LM/W | >110LM/W | >110LM/W | >110LM/W |
Product Size | 703X280X120 mm | |||
CCT | 3000-6500K | |||
RA | >70 | |||
Beam angle | 120° x 90° | |||
Light body material | Die-cast lamp body + glass lens | |||
Protection level | IP66&IK10 | |||
Work temp | —30℃~+50℃ | |||
Work humidity | 10%~90% | |||
Life/Warranty | 50,000hrs / 5YEARS | |||
FAQ:
1. What are your market reach throughout the regiion?
Our markets around the world in every corner, we have many years of experience in foreign trade.Our clients are from different countries. And we have branch office in Spain and Nigeria.
2. Whar are your main products?
Our main products are led outdoor lightings including led flood light( stadium lighting), led high bay light, led street lighting and led garden light.
3. Are you a manufactuer or a trading company?
We are a professional LED manufacturer.
4. Do you have the ability to do independent research and development?
Our engineering department have the research and development capabilities. We also collect regular customer feedback to research new product.
5. How to contact you?
Welcome to vist our websit (www.chz-lighting.com) to get more information.
