CHZ Lighting - LED Street Light Manufacturer and LED Flood Light Factory Since 2013
CHZ eco-friendly led bay lights supplier on sale
1. CHZ is designed by talented architects or interior designers. They work hard on sorting through all the decoration options, deciding on how to blend colors, selecting materials that cater to the market trend. This product is constructed with an over current protection function
2. With years of quality system management, CHZ acts as the leader of offering the finest led bay lights for customers. Designed with quality heat sink fins, it features good heat dissipation
3. The design of led bay lights based on includes the following several respect mainly: Constructed with top Philips 5050 or 3030 chips, it features high luminous efficiency
4. led bay lights has the virtues such as , which is used in . The product is quick in turning on and off
5. Being a product, led bay lights has such properties as . Its correlated color temperature(CCT) can be customized
200 Watt ceiling lights fixtures led light waterproof workshop led high bay lighting
Product Parameter:
Model | HB15-100WA | HB15-150WA | HB15-200WA |
Power | 100W | 150W | 200W |
LED type | SMD3030 | SMD3030 | SMD3030 |
Number of beads | 192 PCS | 192 PCS | 240 PCS |
Serialization | 32P6S | 32P6S | 40P6S |
Light source voltage | 36V | 36V | 36V |
Drive type | MW / SOSEN | MW / SOSEN | MW / SOSEN |
Operating Voltage | 100-277V | 100-277V | 100-277V |
Dimming method | 0-10V, PMW, Timer, Dali | ||
Power factor PF | >0.95 | >0.95 | >0.95 |
Light effect | >140LM/W | >130LM/W | >130LM/W |
CCT | 3000K/4000K/5000K/6000K | ||
RA | >70 | >70 | >70 |
Beam angle | 60°/110° | ||
Product Size | Φ240x125mm | Φ240x125mm | Φ280x135mm |
Installation method | Hook / lifting ring / E40 lamp holder / square bracket, optional | ||
Lamp body material | Die casting lamp body + PC lens | ||
Protection level | IP54 | ||
Operating temperature | —40℃~+50℃ | ||
Working humidity | 10%~90% | ||
Life/warranty period | 50,000hrs / 5 Years | ||
Specification of led high bay lighting
CHZ-ST30 CHZ-ST20 CHZ-ST25
CHZ-ST12 CHZ-ST13 CHZ-ST15B
Company Features
1. Shanghai CHZ Lighting Co.,Ltd's service in led bay lights industry ranks first in the domestic industry.
2. CHZ has been insisting on independent innovation technology to establish its own core business.
3. We pursue continuous improvement to adapt to the changing market. We continue to invest in research and development, continue to set higher standards and expectations for ourselves, and strive to achieve more important milestones. Contact us!
