Top high bay led lighting supply for factories
MODEL:
CHZ-HB28
LED CHIPS:
OSRAM 2835
COLOR TEMPERATURE:
3000K / 4000K / 5000K / 5700K / 6500K
DRIVERS:
SOSEN
BEAM ANGLE:
60°/90°/110°
REGULATION:
0-10V+12V / 1-10V / DALI
VOLTAGE:
100-277V AC 50/60 Hz
POWER FACTOR:
>0.95
ELECTRICAL CATEGORY:
CLASS I
CLASS II
MATERIALS:
AL housing / PC lens
INSTALLATION:
Ø 60 mm
Ø 40 mm
Ø 42 mm
Recessed
Ceiling
Suspended
LIFETIME / WARRANTY:
50,000 hours / 5 years
WORKING ENVIRONMENT:
- 40ºC ~ + 50ºC / 10%-90%RH
SOLAR PANEL:
15-20DAYS
PROTECTION(IP - IK - KV):
IP65 - IK08 - 4KV
LUMEN:
170LM/W
DISCHARGE TEMP:
MS2.0
CRI:
80
CONTROL METHOD:
T/T, L/C,Western Union
CERTIFICATIONS:
CB CE TUV ROHS ISO9001 ISO14001 ISO50001 ISO45001
BATTERY:
SHANGHAI PORT
high bay led lighting
description
This product is able to achieve maximum light output in a matter of seconds. being arranged in an orderly manner, its bulb can work simultaneously and provide full brightness in one second. It is able to work under humidity ranging from 10% to 90
high bay led lighting
SPECIFICATIONS
| MODEL | CHZ-HB28 |
|---|---|
| LED CHIPS | OSRAM 2835 |
| COLOR TEMPERATURE | 3000K / 4000K / 5000K / 5700K / 6500K |
| LUMEN | 170LM/W |
| DRIVERS | SOSEN |
| BEAM ANGLE | 60°/90°/110° |
| REGULATION | 0-10V+12V / 1-10V / DALI |
| VOLTAGE | 100-277V AC 50/60 Hz |
| CRI | 80 |
| POWER FACTOR | >0.95 |
| MATERIALS | AL housing / PC lens |
| PROTECTION(IP - IK - KV) | IP65 - IK08 - 4KV |
| LIFETIME / WARRANTY | 50,000 hours / 5 years |
| WORKING ENVIRONMENT | - 40ºC ~ + 50ºC / 10%-90%RH |
| CERTIFICATIONS | CB CE TUV ROHS ISO9001 ISO14001 ISO50001 ISO45001 |
With a high transmittance light guide plate, it provides a uniform light-emitting effect. It is suitable to apply in the parking lot, garage, high-bay workshop, stadiums, etc. This product is constructed with an over current protection function.
