CHZ Lighting - LED Street Light Manufacturer and LED Flood Light Factory Since 2013
Custom made led yard light manufacturer for street
MODEL:
CHZ-GD34A
LED CHIPS:
LUMILEDS 3030
COLOR TEMPERATURE:
3000K / 4000K / 5000K / 5700K / 6500K
DRIVERS:
SOSEN / INVENTRONICS
BEAM ANGLE:
TYPE II TYPE V
REGULATION:
0-10V / Timer / DALI
VOLTAGE:
100 - 277V / 200~240V
POWER FACTOR:
> 0.95
ELECTRICAL CATEGORY:
Class I / Class II
MATERIALS:
AL housing / AL heatsink / PC lens
INSTALLATION:
Ø 76mm – Ø 40/42/50 mm with adapter (optional)
LIFETIME / WARRANTY:
50,000 hours / 5 years
WORKING ENVIRONMENT:
- 40ºC ~ + 55ºC / 10%-90%RH
SOLAR PANEL:
15-20DAYS
PROTECTION(IP - IK - KV):
IP66 - IK09 - 10KV
DISCHARGE TEMP:
MS2.0
CONTROL METHOD:
T/T, L/C,Western Union
CERTIFICATIONS:
CB CE ENEC ROHS ISO9001 ISO14001 ISO50001 ISO45001
BATTERY:
SHANGHAI PORT
led yard light
description
The product meets stringent quality and regulatory requirements. It is widely exported to over 60 countries and regions
led yard light
SPECIFICATIONS
| MODEL | CHZ-GD34A |
|---|---|
| LED CHIPS | LUMILEDS 3030 |
| COLOR TEMPERATURE | 3000K / 4000K / 5000K / 5700K / 6500K |
| DRIVERS | SOSEN / INVENTRONICS |
| BEAM ANGLE | TYPE II TYPE V |
| REGULATION | 0-10V / Timer / DALI |
| VOLTAGE | 100 - 277V / 200~240V |
| POWER FACTOR | > 0.95 |
| ELECTRICAL CATEGORY | Class I / Class II |
| MATERIALS | AL housing / AL heatsink / PC lens |
| PROTECTION(IP - IK - KV) | IP66 - IK09 - 10KV |
| INSTALLATION | Ø 76mm – Ø 40/42/50 mm with adapter (optional) |
| LIFETIME / WARRANTY | 50,000 hours / 5 years |
| WORKING ENVIRONMENT | - 40ºC ~ + 55ºC / 10%-90%RH |
| CERTIFICATIONS | CB CE ENEC ROHS ISO9001 ISO14001 ISO50001 ISO45001 |
It does not contain lead that poses health risks. It is able to run under extra-low voltage. Adopting an intelligent constant current driver, it has no flicker problem.
