CHZ Lighting - LED Street Light Manufacturer and LED Flood Light Factory Since 2013
CHZ solar parking lot light distributor for engineering
MODEL:
CHZ-IST10
LED CHIPS:
LUMILEDS 3030
COLOR TEMPERATURE:
4000K / 5000K / 5700K / 6500K
BEAM ANGLE:
TYPE II-S
REGULATION:
PIR / Timer
VOLTAGE:
12V/24V automatic adaptation
ELECTRICAL CATEGORY:
CLASS I
CLASS II
MATERIALS:
AL housing / AL heatsink / PC lens
PROTECTION(IP / IK):
IP66 - IK09
INSTALLATION:
Ø 60 mm
Ø 40 mm
Ø 42 mm
Recessed
Ceiling
Suspended
WORKING ENVIRONMENT:
30,000 hours / 3 years
STORAGE TEMP:
- 20ºC ~ + 45ºC / 10%-90%RH
SOLAR PANEL:
Monocrystalline
ON HOURS:
2H- 100% 4H- 100%/50% 6H- 100%/30% (default)
LUMEN:
160LM/W
DISCHARGE TEMP:
- 30ºC ~ + 60ºC
CONTROL METHOD:
ON/OFF switch + Timer regulation + PIR microwave sensor
CERTIFICATIONS:
CE ROHS
BATTERY:
Lithium Li-NCM
solar parking lot light
description
The product is highly resistant to shock, vibrations, and external impacts, which makes it easily exposed to rough conditions indoor or outdoor. With a compact integrated design, it is easy for transportation
solar parking lot light
SPECIFICATIONS
| MODEL | CHZ-IST10 |
|---|---|
| LED CHIPS | LUMILEDS 3030 |
| COLOR TEMPERATURE | 4000K / 5000K / 5700K / 6500K |
| LUMEN | 160LM/W |
| REGULATION | PIR / Timer |
| VOLTAGE | 12V/24V automatic adaptation |
| BATTERY | Lithium Li-NCM |
| SOLAR PANEL | Monocrystalline |
| ON HOURS | 2H- 100% 4H- 100%/50% 6H- 100%/30% (default) |
| BEAM ANGLE | TYPE II-S |
| MATERIALS | AL housing / AL heatsink / PC lens |
| CONTROL METHOD | ON/OFF switch + Timer regulation + PIR microwave sensor |
| PROTECTION(IP / IK) | IP66 - IK09 |
| DISCHARGE TEMP | - 30ºC ~ + 60ºC |
| STORAGE TEMP | - 20ºC ~ + 45ºC / 10%-90%RH |
| WORKING ENVIRONMENT | 30,000 hours / 3 years |
| CERTIFICATIONS | CE ROHS |
The product is quick in turning on and off. With a compact integrated design, it is easy for transportation. Having little electricity consumption, it is energy-keeping.
